Industrial Pneumatic Components · JJDD and JJDAD Series Twin-Rod Fixture Cylinders

JJDD and JJDAD Series Twin-Rod Fixture Cylinders

JJDD and JJDAD Series Twin-Rod Fixture Cylinders for industrial production automation.

Mode A · Single SeriesOne base model with selectable sizes / variants.
JJDD Twin-Rod Fixture Cylinder — Carroland Pneumatics
Select model
JJDD and JJDAD Series Twin-Rod Fixture Cylinders

JJDD Twin-Rod Fixture Cylinder

Double-acting twin-rod fixture cylinder for stable linear clamping motion.

Bore Diameter20, 25, 32, 40, 50, 63, 80, 100 mm
Stroke5-55 mm, depending on bore
Operation ModeDouble acting, twin rod
Working MediumAir
Request a Quote Consult Engineers

Technical Specifications

Bore Diameter20, 25, 32, 40, 50, 63, 80, 100 mm
Stroke5-55 mm, depending on bore
Operation ModeDouble acting, twin rod
Working MediumAir
Operating Pressure Range1.5-7 kgf/cm2
Operating Temperature Range0-60 C
