JJD and JJSI(O) Series Fixture Cylinders

Name: JJD and JJSI(O) Series Fixture Cylinders
Brand: Carroland

JJD and JJSI(O) Series Fixture Cylinders for industrial production automation.

Select model

JJD Standard Fixture Cylinder

Double-acting standard fixture cylinder with optional magnetic sensing.

Bore Diameter12, 16, 20, 25, 32, 40, 50, 63, 80, 100 mm

StrokeSee PDF dimensional tables by bore

Operation ModeDouble acting

Working MediumAir

Request a Quote Consult Engineers

Bore Diameter	12, 16, 20, 25, 32, 40, 50, 63, 80, 100 mm
Stroke	See PDF dimensional tables by bore
Operation Mode	Double acting
Working Medium	Air
Operating Pressure Range	1.5-7 kgf/cm2 for 12-25 mm; 1-7 kgf/cm2 for 32-100 mm
Operating Temperature Range	0-60 C
