Industrial Pneumatic Components · JJCB and JJCF Series Slide Fixture Cylinders

JJCB and JJCF Series Slide Fixture Cylinders

JJCB and JJCF Series Slide Fixture Cylinders for industrial production automation.

Mode A · Single SeriesOne base model with selectable sizes / variants.
JJCB Side-Mount Slide Fixture Cylinder — Carroland Pneumatics
Select model
JJCB and JJCF Series Slide Fixture Cylinders

JJCB Side-Mount Slide Fixture Cylinder

Slide fixture cylinder with side-mount configuration for tooling applications.

Bore Diameter20, 25, 32, 40, 50, 63 mm
Stroke10-150 mm, depending on bore
Operation ModeDouble acting, slide fixture, side mount
Request a Quote Consult Engineers

Technical Specifications

Bore Diameter20, 25, 32, 40, 50, 63 mm
Stroke10-150 mm, depending on bore
Operation ModeDouble acting, slide fixture, side mount
