Rotary clamps, thin cylinders, zero-stroke units, modular grippers and double-force actuators - engineered for the cycle time, precision and cleanroom demands of smartphone, tablet and wearable device assembly. One supplier, from a single clamp to a full fixture system.
Every component below is used in 3C / smartphone assembly. Single-series categories open a model-switch series page; multi-series categories bundle two or more distinct product families under one clamping concept.
Fast 90 degree swing and short stroke action matched to high-takt assembly.
Tight bore/stroke tolerance and anti-rotation options for repeatable locating.
Non-lubricated, filtered-air operation suitable for electronics handling.
Compact bodies let you nest more stations per fixture plate.
Anti-rotation grippers hold housings and carriers without twist, which keeps pick-and-place accurate across millions of cycles on a smartphone line.
Yes. We are a certified supplier for consumer electronics production lines and support drawing-based customization, lot traceability and PPAP-style documentation.
Every series ships with STEP/Parasolid CAD and a spec sheet for direct import into your fixture CAD.
Send your drawing or line spec. Our automation engineers respond with sizing, lead time and a quote, typically within one business day.
3C automation is among the most demanding benchmarks in 3C manufacturing. Every clamping, handling and insertion station must hold tolerances in the tens of microns while running at line takt times below two seconds. Carroland Pneumatics designs and manufactures the pneumatic fixture and clamping systems that hold this precision across the full smartphone and 3C assembly line — from glass and housing handling to camera-module and flex insertion.
Our pneumatic clamping solutions cover the core 3C automation stations: glass panel locating and lamination clamping, middle-frame holding fixtures, camera-module pick-and-place anticipation, FPC flexible-cable insertion jigs, and final-assembly torque-assisted pressing. Each station is built around our ISO 15552 and compact cylinder platforms combined with tailored locating clamps.
Carroland supports 3C automation builders from fixture concept and pilot validation through to high-volume series supply. European technology and China manufacturing since 1992 give us the engineering depth and cost structure to scale with the world’s leading electronics brands.
Explore our pneumatic cylinder guide, pneumatic systems for 3C automation, and the India-specific 3C automation programme.
